RUCKUS® T350 Outdoor Access Point
Outdoor 2x2:2 2.4/5GHz Wi-Fi 6 access points with omni and directional antennae

CommScope RUCKUS Products
RUCKUS T350C Series
RUCKUS ZoneFlex T350 Outdoor 2x2:2 2.4/5GHz Wi-Fi 6 access points with omni and directed antennae
One Ethernet port, PoE input.-20°C to 65°C Operating Temperature. Includes mountingbracket and one year warranty. Does not include PoE injector
#901-T350-US20
Get a Quote!
RUCKUS T350d Series
T350d, omni, outdoor access point, 802.11ax 2x2:2 internal BeamFlex+, dual band concurrent.
One Ethernet port, PoE input, DC input and USB port. -40°C to 65°C operating Temperature. Includes mounting bracket and one year warranty. Does notinclude PoE injector
#901-T350-US40
Get a Quote!
RUCKUS T350se Series
T350se, sector+external, outdoor access point, 802.11ax 2x2:2, internal 120 degree sector + external antenna capable, dual band concurrent access point.
One Ethernet port, PoE input, DC input and USB port. -40°C to 65°C Operating Temperature. Includes adjustable mounting bracket and one year warranty. Does not include PoE injector.
#901-T350-US51
Get a Quote!
WatchDog End User Support, Standalone T350
WatchDog End User Support, Standalone T350, 1 Year
#806-T350-1000
Our Price: $191.10
WatchDog End User Support, Standalone T350, 3 Year
#806-T350-3000
Our Price: $382.20
WatchDog End User Support, Standalone T350, 5 Year
#806-T350-5000
Our Price: $573.30

More pricing below, click here!

Overview:

Outdoor 802.11ax 2x2:2 Wi-Fi Access Points

Modern Wi-Fi device users expect reliable connectivity—anywhere, anytime. But in crowded outdoor venues with thousands of users and constant RF noise, they are often frustrated by poor coverage, dropped connections, and reduced data rates. These aggravating Wi-Fi experiences can easily translate to negative perceptions of the venue and the service provider, resulting in loss of business. The quality of the network experience becomes the "litmus test" for acceptance or rejection.

As the market leader in outdoor Wi-Fi deployments, RUCKUS knows that one AP solution cannot meet every possible challenge of varied and complex outdoor requirements. This is why the RUCKUS T350 Wi-Fi 6 series is designed with more variety than any other outdoor AP in the market today. Available with either internal omni-directional antennas or internal high-gain directional antenna models, the T350 Series uses patented RUCKUS antenna optimization and interference mitigation technologies to improve throughput, connection reliability, and deliver industry-leading Wi-Fi 6 performance to every connected client. At the same time, the T350 Series is designed for fast, simple installation with an ultra-lightweight, low profile, IP-67 rated enclosure that can stand up to the most challenging outdoor environments.

At RUCKUS, we know that outdoor AP deployments are especially challenging for installation and maintenance, which is why RUCKUS outdoor APs use a variety of technologies, like SmartMesh that help simplify outdoor AP deployment.

The RUCKUS T350 Series is perfect for high-density outdoor public venues such as airports, convention centers, plazas, malls, smart cities, and other dense urban environments. By providing a superior Wi-Fi experience to every user in high-density outdoor locations, venue operators can improve guest satisfaction and loyalty, deliver new kinds of wireless application services, and increase revenues.

The RUCKUS T350 Series incorporates patented technologies found only in the RUCKUS Wi-Fi portfolio.

  • Extended coverage with patented BeamFlex+ utilizing multi-directional antenna patterns.
  • Improve throughput with ChannelFly, which dynamically finds less congested Wi-Fi channels to use.

Whether you're deploying ten or ten thousand APs, the T350 Series is easy to manage through RUCKUS' appliance and virtual management options.

Benefits:

SIMPLICITY RUCKUS' Outdoor APs make Wi-Fi deployments extremely simple to deploy with one-touch technologies like SmartMesh™.

STUNNING WI-FI PERFORMANCE Extends coverage with patented BeamFlex+TM adaptive antenna technology while mitigating interference by utilizing up to 64 directional antenna patterns.

GREAT OUTDOOR WI-FI Experience high performance outdoor Wi-Fi 6 with IP-67 weather proofing

MULTIPLE MANAGEMENT OPTIONS Manage the T350 Series with physical or virtual controller appliances.

AUTOMATE MORE DEVICES ChannelFly® dynamic channel technology uses machine learning to automatically find the least congested channels. You always get the highest throughput the band can support.

SERVE MORE DEVICES Connect more devices simultaneously with two MUMIMO spatial streams and concurrent dual-band 2.4/5GHz radios while also enhancing non-11ax device performance

MORE THAN WI-FI Enhance your network with Cloudpath security and management software, SPoT real-time Wi-Fi location engine and analytics software, and SCI network analytics.

Specifications:

WI-FI
Wi-Fi Standards
  • IEEE 802.11a/b/g/n/ac/ax
Supported Rates
  • 802.11ax: 4 to 1774 Mbps
  • 802.11ac: 6.5 to 867 Mbps
  • 802.11n: 6.5 to 300Mbps
  • 802.11a/g: 6 to 54 Mbps
  • 802.11b: 1 to 11 Mbps
Supported Channels
  • 2.4GHz: 1-13
  • 5GHz: 36-64, 100-144, 149-165
MIMO
  • 2x2 SU-MIMO
  • 2x2 MU-MIMO
Spatial Streams
  • 2 streams SU/MU MIMO 5GHz
  • 2 streams SU/MU MIMO 2.4GHz
Radio Chains and Streams
  • 2x2:2 (5GHz)
  • 2x2:2 (2.4GHz)
Channelization
  • 20, 40, 80MHz
Security
  • WPA-PSK, WPA-TKIP, WPA2-Personal, WPA2-Enterprise, WPA3-Personal, WPA3-Enterprise, AES, 802.11i, Dynamic PSK, OWE
  • WIPS/WIDS
Other Wi-Fi Features
  • WMM, Power Save, Tx Beamforming, LDPC, STBC, 802.11r/k/v
  • Hotspot, Hotspot 2.0
  • Captive Portal
  • WISPr
RF
  T350c T350d T350se
Antenna Type Internal omnidirectional Internal omnidirectional Internal 120 deg sectorized + Ntype female external connectors
BeamFlex+ adaptive internal antennas with polarization diversity
Antenna Gain (max) Up to 3dBi 2.4GHz: 6dBi

5Ghz: 8dBi
Peak Transmit Power (Tx port/chain + 3dB Combining gain) 2.4GHz: 26 dBm

5GHz: 25 dBm
2.4GHz: 26dBm

5Ghz: 25dBm
Frequency Bands
  • ISM (2.4-2.484GHz)
  • U-NII-1 (5.15-5.25GHz)
  • U-NII-2A (5.25-5.35GHz)
  • U-NII-2C (5.47-5.725GHz)
  • U-NII-3 (5.725-5.85GHz)
2.4GHZ RECEIVE SENSITIVITY
HT20 HT40 VHT20 VHT40
MCS0 MCS7 MCS0 MCS7 MCS0 MCS7 MCS0 MCS7
-97 -78 -94 -75 -97 -78 -94 -75
HE20 HE40
MCS0 MCS7 MCS9 MCS11 MCS0 MCS7 MCS9 MCS11
-97 -78 -73 -67 -94 -75 -70 -64
5GHZ RECEIVE SENSITIVITY
VHT20 VHT40 VHT80
MCS0 MCS7 MCS8 MCS9 MCS0 MCS7 MCS8 MCS9 MCS0 MCS7 MCS8 MCS9
-97 -78 -75 -73 -95 -77 -71 -69 -92 -74 -68 -66
HE20 HE40 HE80
MCS0 MCS7 MCS9 MCS11 MCS0 MCS7 MCS9 MCS11 MCS0 MCS7 MCS9 MCS11
-97 -78 -72 -67 -95 -77 -69 -64 -92 -74 -66 -61
2.4GHZ TX POWER TARGET
Rate Pout (dBm)
MCS0 HT20 23
MCS7 HT20 18
MCS8 VHT20 17
MCS9 VHT40 16.5
MCS11 HE40 15
5GHZ TX POWER TARGET
Rate Pout (dBm)
MCS0, VHT20 22
MCS7, VHT40, VHT80 20
MCS9, VHT40, VHT80 19
MCS11, HE20, HE40, HE80 15
PERFORMANCE AND CAPACITY
Peak PHY Rates
  • 2.4GHz: 574 Mbps
    5GHz: 1200 Mbps
Client Capacity
  • Up to 512 clients per AP
SSID
  • Up to 31 per AP
RUCKUS RADIO MANAGEMENT
Antenna Optimization
  • BeamFlex+
  • Polarization Diversity with Maximal Ratio Combining (PDMRC)
Wi-Fi Channel Management
  • ChannelFly
  • Background Scan Based
Client Density Management
  • Adaptive Band Balancing
  • Client Load Balancing
  • Airtime Fairness
  • Airtime-based WLAN Prioritization
SmartCast Quality of Service
  • QoS-based scheduling
  • Directed Multicast
  • L2/L3/L4 ACLs
Mobility
  • SmartRoam
Diagnostic Tools
  • Spectrum Analysis
  • SpeedFlex
NETWORKING
Controller Platform Support
  • SmartZone
  • ZoneDirector
  • Unleashed
  • Cloud
  • Standalone
Mesh
  • SmartMesh™ wireless meshing technology. Self-healing Mesh
IP
  • IPv4, IPv6
VLAN
  • 802.1Q (1 per BSSID or dynamic per user based on RADIUS)
  • VLAN Pooling
  • Port-based
802.1x
  • Authenticator & Supplicant
Tunnel
  • L2TP, GRE, Soft-GRE
Policy Management Tools
  • Application Recognition and Control
  • Access Control Lists
  • Device Fingerprinting
  • Rate Limiting
IoT
  • T350d: Integrated BLE and Zigbee (1 radio, switchable)
PHYSICAL INTERFACES
  T350c T350d T350se
Ethernet 1 x 1GbE port, RJ-45 PoE In - 802.3at Class 4
USB 1 USB 2.0 port, Type A
DC Power 12V DC Terminal Block (7V - 20V)
PHYSICAL CHARACTERISTICS
  T350c T350d T350se
Physical Size
  • 162.3mm (W) x 194.9mm (L) x 80.9mm (H)
  • 6.38in (W) x 7.67in (L) x 3.19in (H)
  • 162.3mm (W) x 213.7mm (L) x 80.9mm (H)
  • 6.38in (W) x 8.41in (L) x 3.19in (H)
  • 209.1mm (W) x 261.7mm (L) x 102.5mm (H)
  • 8.23in (W) x 10.30in (L) x 4.04in (H)
Weight (w/ included bracket) 1.01kg (2.23lbs) 1.07kg (2.36lbs) 2.2kg (4.85lbs)
Ingress Protec੏on IP-67
Mounting
  • Pole Mount
  • Wall Mount
  • Flat Surface
  • Bracket included in the box
Operating Temperature -20°C (4°F) to 65°C (149°F) -40°C -(-40°F) to 65°C (149°F)
Operating Humidity Up to 95%, non-condensing
Wind Survivability Up to 266km/h (165 mph)
Altitude Up to 3,048m (10,000 ft), functional operation
POWER1
    T350c T350d T350se
Power Mode System Configuration Max Power Consumption (includes USB power)
802.3at (PoE) - Class 4 Full Functionality 13.24W 17.57W 21.3W
802.3af (PoE) - Class 3 USB Disabled

IoT Disabled
11.42W 12.94W 12.81W
Idle (PoE)   7.68W 7.78W 8.68W
DC - max power Full Functionality 16.32W 19.34W
DC - idle   6.78W 7.92W
CERTIFICATIONS AND COMPLIANCE
Wi-Fi Alliance2
  • Wi-Fi CERTIFIED™ a, b, g, n, ac
  • Wi-Fi CERTIFIED™ 6
  • WPA3™ - Enterprise, Personal
  • Wi-Fi Enhanced Open™
  • Wi-Fi Agile Multiband™
  • Wi-Fi Optimized Connectivity™
  • Wi-Fi Vantage™
  • WMM®
  • Passpoint®
Standards Compliance3
  • IEC/EN/UL 62368-1 & IEC/EN 60950-1 Safety
  • FCC 15B, RSS-Gen, EN 301 489-1/17
  • EN 61000-3-x Emissions
  • EN 61000-4-2/3/5 Immunity
  • EN 60601-1-2 Medical
  • EN 50121-1/4 Railway EMC
  • IEC 61373 Railway Shock & Vibration
  • UL 2043 Plenum
  • EN 62311 Human Safety/RF Exposure
  • WEEE & RoHS
  • ISTA 2A Transportation
SOFTWARE AND SERVICES
Location Based Services
  • SPoT
Network Analytics
  • SmartCell Insight (SCI)
  • RUCKUS Analytics
Security and Policy
  • Cloudpath
MODEL FEATURE DIFFERENCES
Model Antenna Low Temp USB DC Power
T350c Internal omni -20°C N N
T350d Internal omni -40°C Y Y
T350se Internal sector (120°) + External antenna capable -40°C Y Y

  1. To be available in subsequent release.
  2. For complete list of WFA certifications, please see Wi-Fi Alliance website.
  3. For current certification status, please see price list.

Documentation:

Download the RUCKUS T350 Series Datasheet (PDF).
