Ruckus ZoneFlex R320
Indoor 802.11ac Wave 2 Wi-Fi Access Point

CommScope RUCKUS Products
Ruckus ZoneFlex R320 Series
Ruckus R320 Indoor 802.11ac Wave 2 2x2:2 Wi-Fi Access Point
*Concurrent dual band 802.11ac wave 2 AP, no power adapter
#901-R320-US02
Our Price: $395.00
WatchDog End User Support, Standalone R320
WatchDog End User Support, Standalone R320, 1 Year
WatchDog End User Support, Standalone R320, 1 Year
#806-R320-1000
Our Price: $56.00
WatchDog End User Support, Standalone R320, 3 Year
WatchDog End User Support, Standalone R320, 3 Year
#806-R320-3000
Our Price: $119.00
WatchDog End User Support, Standalone R320, 5 Year
WatchDog End User Support, Standalone R320, 5 Year
#806-R320-5000
Our Price: $158.00

More pricing below, click here!

Overview:

Smaller locations can face big-time demands on their wireless infrastructure. Whether working out of a small office or connecting to a public hotspot, users are often still accessing the same high-bandwidth applications and content they’d consume anywhere else. And they expect strong, reliable connectivity.

The Ruckus R320 delivers consistent, reliable 802.11ac Wave 2 wireless networking at an affordable price. It features the patented Ruckus performance optimization and interference mitigation technologies found in our premier access points to deliver superior user experiences at extended ranges. But it provides them in an ultra-compact form factor built for small and midsize businesses and low-density hotspot environments.

Get industry-leading Wi-Fi performance in a package designed for smaller venues—with a price tag to match.

How can you provide it without breaking the bank? The Ruckus R320 delivers consistent, reliable 802.11ac wave 2 wireless networking at an affordable price. It features the patented Ruckus BeamFlex adaptive antenna technology for performance optimization and interference mitigation found in our premier access points, delivering superior user experiences at extended ranges. But it provides them in an ultra-compact form factor built for small venues—with a price tag to match. The R320 is an ideal choice for low-density enterprise and hotspot environments including smalland medium-size businesses, retail locations, restaurants, and multi-tenant small offices and branch offices. The R320 802.11ac wave 2 Wi-Fi AP incorporates patented technologies found only in the Ruckus WiFi portfolio.

  • Extended coverage with BeamFlex utilizing multi-directional antenna patterns.
  • Improve throughput with ChannelFly, which dynamically finds less congested Wi-Fi channels to use.

The R320 provides an ideal combination of features and performance for smaller environments. Additionally, it supports up to 256 clients per AP. Whether you’re deploying ten or ten thousand APs, the R320 is also easy to manage through Ruckus’ appliance, virtual, controller-less and cloud management options.

Features:

Affordable Enterprise Performance

The R320 provides great performance with extended range at an affordable price.

Keep Existing Switches and Cables

Designed to operate on existing PoE switches and CAT 5e cabling to minimize costly upgrades.

Multiple Management Options

Manage the R320 from the cloud, with on-premises physical/virtual appliances, or without a controller.

Stunning Wi-Fi Performance

Extends coverage with patented BeamFlex adaptive antenna technology while mitigating interference by utilizing 64 directional antenna patterns.

Get Optimal Throughput

ChannelFly dynamic channel technology uses machine learning to automatically find the least congested channels. You always get the highest throughput the band can support.

More Than Wi-Fi

Enhance your network with Cloudpath security and management software, SPoT real-time Wi-Fi location engine and analytics software, and SCI network analytics.

Specifications:



R650

R610

R510

R320

R310





R650 Learn More R610 Learn More R510 Learn More R320 Learn More R310 Learn More



Feature/Description

Mid-range

Wi-Fi 6 (802.11ax) dual- concurrent AP with

MU-MIMO and BeamFlex+

Mid-range

802.11ac Wave 2 dual-concurrent AP with MU-MIMO and BeamFlex+

Mid-range

802.11ac Wave 2 dual-concurrent AP with MU-MIMO and BeamFlex+

Entry level

802.11ac Wave 2 dual-concurrent AP with BeamFlex

Entry level

802.11ac Wave 1 dual-concurrent AP with BeamFlex



Maximum PHY rate

2400 Mbps (5GHz)

574 (2.4GHz)

1300  Mbps (5GHz)

450  Mbps (2.4GHz)

867 Mbps (5GHz)

300 Mbps (2.4GHz)

867 Mbps (5GHz)

300 Mbps (2.4GHz)

867 Mbps (5GHz)

300 Mbps (2.4GHz)



Wi-Fi technology

802.11ax (2.4GHz, 5GHz) Wi-Fi CERTIFIED 6™

802.11ac (5GHz)

802.11n (2.4GHz)

802.11ac (5GHz)

802.11n (2.4GHz)

802.11ac (5GHz)

802.11n (2.4GHz)

802.11ac (5GHz)

802.11n (2.4GHz)

Concurrent users

512

512

512

256

100



Radio chains:streams

5GHz: 4x4:4 MU-MIMO

2.4GHz: 2x2:2 MU-MIMO



3x3:3



2x2:2



2x2:2



2x2:2

Antenna patterns (per band)

128

512

64

64

64

Antenna gain

Up to 3dBi

Up to 3dBi

Up to 3dBi

Up to 3dBi

Up to 3dBi

PD-MRC

Rx sensitivity (2.4/5GHz)

-101dBm

-100dBm

-103dBm

-101dBm

-99dBm

ChannelFly

SmartMesh

USB (IoT Ready)



Ethernet ports

1 x 1 GbE

1 x 2.5 GbE



2 x 1GbE



2 x 1GbE



1 x 1GbE



1 x 1GbE

Integrated BLE/ZigBee



WLAN Control and Management

·   ZoneDirector

·   SmartZone

·   RUCKUS Cloud

·   ZoneDirector

·   SmartZone

·   Unleashed

·   RUCKUS Cloud

·   ZoneDirector

·   SmartZone

·   Unleashed

·   RUCKUS Cloud

·   ZoneDirector

·   SmartZone

·   Unleashed

·   RUCKUS Cloud

·   ZoneDirector

·   SmartZone

·   Unleashed

·   RUCKUS Cloud

Documentation:

Download the Ruckus ZoneFlex R320 Datasheet (PDF).
